Digital Rheometer

Digital Rheometer Specification

Display Type
Large LCD Display

Heating Capacity
Integrated temperature control system

Shape
Rectangular

Accuracy
1% FS

Features
Programmable, Easy to operate, Auto-calibration, Overload protection

Temperature Resistance
Up to 150C

Speed Range
0.1 200 RPM

Power Supply
AC 220V 50Hz

Control Type
Digital Microprocessor Control

Type
Digital Rheometer

Dimension (L*W*H)
360 x 300 x 450 mm

Equipment Type
Laboratory Rheometer

Equipment Materials
Stainless Steel, ABS Plastic

Power
40 W

Voltage
220 V AC

Material
Stainless Steel, High Quality Plastics

Application
Measuring viscosity and rheological properties of fluids

Measurement Range
10 2,000,000 mPas

Compliance
ISO, ASTM Standards

Safety Features
Automatic stop on overload/error

Weight
~12 kg

Ambient Humidity
80% RH

Data Output
USB/RS232 Interface

Color
White/Grey body

Operating Temperature Range
0C 150C

Sample Volume
20 30 ml

Packaging
Foam packed in sturdy box for protected transport

Software Compatibility
Windows-based analysis software

Rotors
4 Standard (others optional)

About Digital Rheometer

Sophisticated Rheometer with continuous sensing and display.
Stand-alone programming: Enter data, temperature requirements, start program, see results on built-in display.
Computer programmable using optional Rheocalc 32 software lets you control all aspects of rheological testing directly from the computer.
The tool to easily predict a materials flow, spray or pumping behaviour by studying shear rate profiles.
Has built-in math models for data analysis in stand-alone mode, eg. Casson.
Complete with appropriate spindles, Rheoloader program, power base, guard leg and carrying case.

Accuracy: 1.0% of range Repeatability: 0.2%

Advanced Viscosity Measurement

This digital rheometer offers accurate viscosity assessment within a range of 10 to 2,000,000 mPas, suitable for different fluid types used in chemical, pharmaceutical, food, and materials science laboratories. Its programmable features and automatic calibration ensure consistent and precise results every time.

User-Friendly and Robust Design

Constructed from stainless steel and high-quality plastics, the rheometer is housed in a white/grey rectangular body, making it durable and easy to clean. The foam-packed sturdy box ensures safe transit, and the device weighs approximately 12 kg for manageable laboratory handling.

Comprehensive Data Connectivity and Analysis

Equipped with both USB and RS232 data output interfaces, this instrument allows effortless data transfer to computers running Windows-based analysis software. This facilitates automatic report generation, trend analysis, and documentation compliant with ISO and ASTM standards.

FAQ's of Digital Rheometer:

Q: How does the Digital Rheometer ensure accurate viscosity measurements across a broad range?

A: The digital rheometer features a high-precision microprocessor control and offers an accuracy of 1% full scale, ensuring reliable and repeatable viscosity measurements between 10 and 2,000,000 mPas. It auto-calibrates before use, and its integrated temperature control stabilizes samples, further improving measurement accuracy.

Q: What safety features are available on this digital rheometer for laboratory use?

A: The rheometer comes equipped with automatic stop functionality that activates during overload or error conditions, protecting both the user and the device. The system also has overload protection built into its programmable control, ensuring safe operation even with frequent or high-volume use.

Q: When should I use the different standard rotors supplied with the equipment?

A: The four standard rotors are designed for different viscosity ranges and sample types. Choosing the appropriate rotor depends on your specific sample viscosity and measurement requirements; additional rotor options are available to extend the instrument's versatility for unique applications.

Q: Where is the ideal environment for operating this laboratory rheometer?

A: This device operates best in controlled laboratory environments with ambient humidity not exceeding 80% RH and temperatures within the specified range of 0C to 150C. Such conditions ensure optimal instrument performance and measurement reliability.

Q: What is the process for exporting data and conducting analysis with the supplied software?

A: Measurement data can be exported directly via the integrated USB or RS232 interfaces to a PC running the compatible Windows-based analysis software. The software streamlines data analysis, report generation, and facilitates compliance with ISO and ASTM standards.

Q: How does this rheometer benefit research and quality control in various industries?

A: The digital rheometer provides rapid, precise viscosity and rheological measurements, helping scientists and quality control personnel monitor fluid properties for product consistency, formulation development, and regulatory compliance, ultimately boosting productivity and reliability.
