Colloidal Mill

Colloidal Mill Specification

Features
Leak-proof design, Easy to operate, Low maintenance, Sturdy construction

Control Type
Manual / Optional Automated

Speed Range
2800 RPM

Temperature Resistance
Up to 90C

Accuracy
High Precision

Power Supply
Electric

Shape
Vertical Cylindrical

Type
Colloidal Mill

Dimension (L*W*H)
800 x 420 x 875 mm

Equipment Type
Milling Equipment

Equipment Materials
Stainless Steel

Power
2 HP

Voltage
220/380 V

Material
SS 304 / SS 316

Application
Mixing, Emulsification, Homogenization, Dispersion and Wet Milling

Capacity (Ltr)
5 to 50 Liters per hour

Mounting
Table/stand-mounted

Sealing System
Triple mechanical seal with water cooling

Suitable for
Pharmaceutical, Food, Chemical, Cosmetic industries

Feed Hopper Volume
Approx. 15 Ltr

Weight
Approx. 70 kg

Surface Finish
Mirror/Matte

Noise Level
< 75 dB

Construction
Compact, portable unit

Rotor-Stator Clearance
Adjustable (0.2-1 mm)

Discharge
Bottom outlet with valve

Fineness Achievable
Up to 5 micron

About Colloidal Mill

It has excellent function in superfine dispersing, emulsifying, homogenizing and complex mixing etc. After grinding, the particle size of materials processed will be reduced to 3-50 microns and the homogeneity more than 90%. It is an ideal equipment for superfine complex processing of corpuscles instead of such as homogenizer, ball grinding mill, three-roller mill, agitator etc, but is several times more efficient than those above. It may be used widely in various processing industries such as food-stuff, pharmaceutical, chemical, cosmetic, light and plastic etc. Machine to work on 220V AC 50 Hz single phase.

High-Performance Fineness and Precision

Achieve up to 5-micron particle size with the advanced rotor-stator system, delivering high accuracy and consistent product quality. The adjustable clearance offers precise control, catering to different processing needs across industries.

Robust Build for Versatile Applications

Crafted from durable SS 304/316 stainless steel, the colloidal mill is built for maximum strength and corrosion resistance. Its leak-proof design and high-temperature resistance (up to 90C) make it suitable for pharmaceutical, food, chemical, and cosmetic processes.

Efficient and User-Friendly Operation

With a compact, portable structure, easy manual (or optional automated) control, and a low-maintenance design, this milling equipment streamlines workflows. The triple-seal, water-cooled system ensures safe, quiet, and efficient operation.

FAQs of Colloidal Mill:

Q: How does the adjustable rotor-stator clearance benefit the colloidal milling process?

A: The adjustable rotor-stator clearance (0.21 mm) allows precise control over the particle size during processing, making it possible to achieve fine dispersions up to 5 microns. This flexibility makes the equipment suitable for various products and guarantees consistent results.

Q: What industries can use this colloidal mill, and for which processes?

A: This colloidal mill is suitable for the pharmaceutical, food, chemical, and cosmetic industries. It is ideally used for mixing, emulsification, homogenization, dispersion, and wet milling of products needing high fineness and uniformity.

Q: When is this colloidal mill recommended over other types of milling equipment?

A: This equipment is recommended when high precision, superior fineness (up to 5 microns), and hygienic processing are required, particularly for semi-liquid or liquid-based formulations in industries such as pharmaceuticals, food processing, and cosmetics.

Q: Where should the colloidal mill be mounted for optimal operation?

A: The unit features a versatile design that allows it to be table or stand-mounted, ensuring stable and safe operation in production and laboratory environments according to available space and workflow requirements.

Q: What is the process for operating and adjusting this colloidal mill?

A: Operation is straightforward: load the material into the 15-liter feed hopper, set the desired rotor-stator clearance, and start the unit using manual or automated controls. The triple mechanical seal with water cooling ensures leak-proof and safe continuous operation.

Q: What are the main benefits of using this colloidal mill?

A: Key benefits include precise particle size control, ease of operation, low noise levels (<75 dB), robust stainless steel construction, high temperature resistance, leak-proof design, and low maintenance, all conducive to efficient production and superior end-product quality.
