Bottle Washing Machine

Bottle Washing Machine Specification

Display Type
Digital

Temperature Resistance
Up to 80C

Features
Automatic Loading/Unloading, Modular Design, Low Water Consumption, Easy Maintenance

Power Supply
Three Phase / Single Phase

Shape
Rectangular

Accuracy
High Precision Cleaning

Glass Type
All Standard Bottle Types

Control Type
PLC Control Panel

Speed Range
Variable, up to 120 BPM

Type
Rotary Bottle Washing Machine

Dimension (L*W*H)
2000 mm x 1250 mm x 1600 mm

Equipment Type
Automatic Bottle Washer

Equipment Materials
Stainless Steel (SS304/SS316)

Power
2 HP

Voltage
230V/415V, 50 Hz

Material
Stainless Steel

Application
Washing Bottles in Pharmaceutical, Food, and Beverage Industries

Capacity (Ltr)
40-120 Bottles Per Minute

Construction
GMP & cGMP Compliance

Noise Level
Low Noise Operation (<75 dB)

Safety Features
Overload Protection, Emergency Stop, Safety Guards

Usage
Industrial Cleaning Bottles, Vials, Jars

Cleaning Cycles
4-6 Multiple Cycles with Different Media

Automation
Full Automatic with Synchronization

Weight
Approx. 700 kg

Water Consumption
Approx. 300-500 Liters per Hour

Nozzles
Adjustable Spray Nozzles for Inner & Outer Cleaning

Bottle Size Range
30 ml to 1000 ml

About Bottle Washing Machine

Bottle Washing Machines rendered with great versatility and can adapt to the most wide-ranging range of necessities. These have an extremely compact design and ensure low consumptions and practically zero upkeep as there are zero mechanical organs. These come with the functionalities of a traditional bottle washer as well as high quality washing. Also, these insure removal of the labels as well as bottle rinsing. Bottle Washing Machines are particularly compact machines, which have been designed according to the clients indications. Bottle Washing Machines are extremely versatile and can acclimate to the most varied variety of client requirements.

Advanced Cleaning Technology

Benefit from multiple cleaning cycles using different media and advanced adjustable spray nozzles, ensuring a comprehensive, high-precision wash for bottles, vials, jars, and nozzles. Each cycle is specifically designed for optimal removal of contaminants to meet stringent industry standards.

Fully Automatic & User-Friendly

This machine features full automation with a synchronized operation and a PLC control panel, offering digital control and variable speed up to 120 bottles per minute. Automatic loading and unloading streamline the process for maximum efficiency.

Built for Safety and Compliance

The unit is manufactured with high-grade stainless steel (SS304/SS316) for durability and hygiene. Overload protection, safety guards, and an emergency stop ensure the highest levels of operator safety. The low-noise design (<75 dB) creates a comfortable working environment.

Efficient and Sustainable Operation

With water consumption limited to approximately 300-500 liters per hour, the machine conserves resources while maintaining superior cleaning performance. The modular design makes maintenance straightforward, supporting long-term sustainable use.

FAQ's of Bottle Washing Machine:

Q: How does the Bottle Washing Machine ensure thorough cleaning of various container types?

A: The machine utilizes 4-6 cleaning cycles with different media and adjustable spray nozzles for inner and outer surfaces, guaranteeing precise and effective cleaning of bottles, vials, jars, and nozzles.

Q: What industries can benefit from using this Rotary Bottle Washing Machine?

A: This equipment is ideal for industries such as pharmaceuticals, food, and beverages, where high standards of cleanliness, safety, and compliance are required for all types of standard bottles.

Q: When is this machine recommended for use in a production process?

A: The machine is suitable wherever high-volume, precise, and sanitary cleaning of bottles (30 ml to 1000 ml) is needed, especially before filling processes in manufacturing lines operating up to 120 bottles per minute.

Q: Where should this machine be installed for optimal performance?

A: It should be placed in a clean, industrial environment with an appropriate power supply (230V/415V, 50Hz), ideally close to bottle filling and packaging lines for streamlined workflow integration.

Q: What is the process flow for cleaning bottles in this automatic washer?

A: Bottles are automatically loaded onto the machine, passed through synchronized rotary modules, and subjected to multiple cleaning cycles using various media under adjustable spray nozzles, followed by automatic unloading.

Q: How does the modular design and compliance benefit operators and maintenance staff?

A: The modular, GMP & cGMP-compliant construction allows easy access for cleaning and part replacement, simplifying routine maintenance and ensuring continuous adherence to industry regulations.

Q: What are the primary advantages of using this automatic bottle washer in terms of operational efficiency?

A: Key benefits include high cleaning accuracy, fast cycle speeds, automated operation, low water consumption, low noise, enhanced safety, and a digital PLC interface for easy monitoring and precise control.
